Laser power: 100W
Laser Type: CO2 Sealed-off Glass-tube laser
Control Software: Vision system.
Power supply: AC 110V-220V?10% / 50-60Hz
Max. Engraving size: 1800 * 1000mm
Cutting speed: 0-30,000mm/min
Working Table : Conveyor working table
Positioning Accuracy: <0.1mm
Min. shaping character: Character: 2x2mm, Letter: 1x1mm
Driving System: Offline Servo Motor Control System , LCD Screen
Cooling System: water-cooling and protection system
Graphic Format Supported: CorelDraw, AutoCAD, Photoshop
File Format Supported: BMP, CIF, JPEG, TGA, TIFF, PLT, AI, DXF, DWG etc
Machine Dimension: 2080*1430*920mm
Packing Dimension: 2190*1540*1120mm
Net Weight: 300kg.
Auto Feeding System: Yes, continuous cutting
1). Large format recognition continuous cutting
This function is for patterned fabric precisely positioning and cutting. For example, through digital printing, various graphics printed on garment fabric. In the subsequent of positioning and cutting, material information extracted by the high-speed industrial camera (CCD), software smart identification closed outer contour graphics, then automatically generates the cutting path and finish cutting. Without the need for human intervention, it can achieve continuous recognition cutting of the entire roll printed fabrics.
I.e. by large format visual recognition system, the software automatically recognize the contour pattern of the garment, and then automatic contour cutting graphics, thus ensuring accurate cutting of the fabric.
Advantage of contour detection:
-No required the original graphics files
-Directly detect roll printed fabrics
-Automatic without manual intervention
-Identification within 5 seconds on the whole cutting area.
2). Printed Marks Cutting
This cutting technology is applicable to a variety of patterns and labels precision cutting. Especially suitable for automatic continuous printing clothing contour cutting. Marker point positioning cutting no pattern size or shape restrictions. Its positioning is only associated with two Marker points. After two Marker points to identify the location, entire format graphics can be precisely cut. (Note: arrangement rules must be the same for each format of the graphic. Automatic feeding continuous cutting, to be equipped with feeding system.)
Xem thêm: máy laser cắt vải
Advantage of printed marks detection:
-Unlimited for the distance between printed pattern
-Unlimited for printing design and background color
-Compensation of processing material deformation
3). Strips and Plaids Cutting
CCD camera, which is installed in the rear of the cutting bed, can recognize materials information such as stripes or plaids according to color contrast. The nesting system can perform automatic nesting according to the identified graphical information and cut pieces requirement. And can automatically adjust the pieces angle to avoid stripes or plaids distortion on the feeding process. After nesting, the projector would emit red light to mark the cutting lines on materials for calibration.
4). Square Cutting for Banners
If you only need to cut square and rectangle, if you don’t have high requirement about cutting precision, you can choose below system.
Work flow: small camera detect the printing marks and then laser cut the square/rectangle.
Laser Cutting Printed Sublimation Fabric for Sportswear Swimwear Shoes Banners Flags
Sportswear, sports garment, swimwear, printed sublimation textile & apparel
Strips & plaids clothing, suits, shirts, dresses
Fabric with Repetitive Visual Motifs
Arabesquitic luxury bags, suitcase, sofa upholstery
Banners, flags, vinyl, polyester
