HQ1530 (CO2 Laser For Non-metal)

Technical Index:

Laser power: 100/130/150/200/250W

Laser Type: CO2 Sealed-off laser glass tube, water-cooled

Engraving size: 1300*2500mm

Engraving speed: 25-10000mm/min

Cutting speed: 25-5000mm/min

Laser Energy Control: Adjustable

Max. Scanning Accuracy: 25-2500DPI

Figure Supported: DST, HPGL (PLT), BMP, DXF, AI, DST, JPEG

Software Supported: TAJIMA, CORELDRAW, PHOTOSHOP, AUTOCAD, CAM

Color Separation: Yes, 256 layers

Machine Dimension: 2120*3420*1150mm

Packing size: 2190*1540*1120mm

Gross weight: 500kgs

Total Power: 1000

Communication Connection: USB (off-line) or computer control

Working Voltage: 220V+/-10% 50Hz, or 110V 60 Hz

Moving System: DSP Professional Controlling System

Repeating Location: <+0.01

Applicable Industry:

Cutting, engraving, through-carved, hole drilling on textile, garment, leather, cotton & linen fabric, glass, wood,

bamboo, arcylic board etc non-metal materials.
